Single Fiber 10km 1310nm 1550nm 1.25G SFP Optical Module

Product Categories

Wuhan Yongxinfeng Science & Technology Co., Ltd.

Contact Now

Single Fiber 10km 1310nm 1550nm 1.25G SFP Optical Module

Name: Single Fiber 10km 1310nm 1550nm 125G SFP Optical Module
Brand: YXFiber
Price: 7.5 USD

Wholesale Single Fiber 10km 1310nm 1550nm 1.25G SFP Optical Module from china suppliers

Brand Name : YXFiber

Certification : CE ROHS ISO9001

Place of Origin : China

MOQ : 50 pairs

Price : usd7.5-usd8.5/pairs

Payment Terms : L/C, T/T

Supply Ability : 10000pcs/day

Delivery Time : 2-3 working days

Packaging Details : anti-static plastic bag

DATA rate : 1.25g

fiber type : single Fiber

wave length : 1310nm/1550nm

transmission distance : 10km

connector : LC

Laser : 1310nm: FP/PIN, 1550nm: DFB/PIN

power supply : 3.3V

warranty : 2 year

Contact Now

1.25g wdm 10km 1310nm/1550nm LC Connector DDM DOM SMF olt SFP Module Transceiver

Technical Parameters	Descriptions	Technical Parameters	Descriptions
Model Number	YXF-GE-B35L-10D, YXF-GE-B53L-10D	Connector	LC
Fiber type	SMF	Laser/Detector	1310nm: FP/PIN 1550nm:DFB/PIN
Form Factor	BIDI SFP	DDM	Yes
Data Rate	1.25Gbps	Output Power	-3~-9dBm
Wavelength	Rx1310/Rx1550nm, Tx1550nm/Rx1310nm	Power Supply	3.3V
Distance	10KM	Temperature	0~70°C
Sensitivity	<-21.0dBm	Certificate	CE,ROHS,FCC,ISO9001,SGS
Selling Units	1 Pair	Warranty	1Year

Features:

1. Up to 1.25 Gbps bi-directional data links
2. Hot-pluggable SFP footprint
3. Simplex LC connector
4. Very low jitter
5. Metal enclosure, for lower EMI
6. Single power supply 3.3V
7. Low power dissipation <700mW
8. Operating temperature range: 0ºC to 70ºC

Parameter	Symbol	Min	Max	Unit
Storage Temperature	TSTG	-40	+85	ºC
Ambient Operating Temperature	T_A	0	70	ºC
Optical Rise/Fall Time	Tr /Tf	-	0.26	ns
Eye Diagram	IEEE 802.3z and ANSI Fibre Channel Compliant
Power Supply Current	Icc	-	200	mA
Extinction Ratio	ER	9	13	dB
Sensitivity	S	-	-24	dBm
Warning	assert>-34dBm,de-assert<-26dBm

Product Tags:

1550nm 1.25G SFP Optical Module

1310nm 1.25G SFP Optical Module

10km sfp fiber module

Single Fiber 10km 1310nm 1550nm 1.25G SFP Optical Module Images
